Explosion Proof UL Approved LED Lights 7W - 20W IP67 Waterproof LED CNC Machine Lights

Delivery Time : 5-8 working days

IP Rating : IP67

Price : $42-46

Lighting solutions service : Lighting And Circuitry Design

Model Number : ONN-M9S

Working Temperature(℃) : -20 - 45

Packaging Details : 9 pieces/carton, 990x210x240mm, N.W. 10kg, G.W. 13kg

Input Voltage(V) : 24V/220V

Place of Origin : Guangdong, China

Supply Ability : 8000pcs 5-12 working days

Color Temperature(CCT) : 6000K (Daylight Alert), 2800-3200K/4000-4500K/6000-6500K

Brand Name : ONLION

Certification : CE/UL

MOQ : 1

Working Hours : 50000

Contact Now

ONN-M9S UL-Listed IP67 CNC Machine Light 24/220V, 300-800mm. Withstands Coolant. No Frequent Burnouts. Long Life.

Product Overview
ONN-M9S is a compact tubular LED machine tool work light from ONN Lighting with UL certification. Constructed with aluminum alloy housing and tempered glass, it adopts integrated sealed design to reach IP67 rating, resisting water, oil, dust and cutting fluid. Equipped with premium LED chips, it delivers uniform, stable illumination with low light decay. Multiple voltage options are available, and the adjustable bracket enables flexible lighting angles. Featuring shock-resistant structure, it fits CNC machines and machining centers. Compact in size and easy to mount, it operates steadily under tough workshop conditions, serving as an ideal lighting option for high-end industrial equipment.

Quick Detail
  • Multiple power options: 7W, 12W, 16W, 20W to satisfy different brightness demands
  • Four available lengths: 300mm, 400mm, 600mm, 800mm for diverse installation space
  • Two voltage choices: B=AC/DC24V, C=AC90-240V, compatible with global machine tools
  • Three color temperatures optional: 6000-6500K cool white, 4000-4500K natural white, 2800-3200K warm white
  • IP67 integrated sealed structure, waterproof, oil-proof, dustproof and anti-cutting fluid splash
  • Aluminum alloy housing and tempered glass, shock-resistant for vibrating machining environment
  • Equipped with adjustable mounting bracket to flexibly adjust lighting angle
  • Compact tubular design, easy to install inside narrow equipment space

Specifications

Parameter Specification
Model ONN-M9S
Power(length) 7W(300mm), 12W(400mm), 16W(600mm), 20W(800mm)
Input voltage(current) AC100-240V(50/60Hz), AC/DC24V
Lumen efficiency 110lm/w
CRI ＞80
Beam angle 115 degree
IP Rating IP67
Color temperature 2800-3200K, 4000-4500K, 6000-6500K
Material Aluminum housing, Tempered glass
Lifetime 50,000 hours
Mounting Screw fixing or hanging
Competitive Advantages
  • Rich Specification Options Available in 7/12/16/20W, lengths of 300/400/600/800mm for various lighting needs.
  • Dual Voltage Compatibility AC/DC24V & AC90-240V optional, compatible with machine tools worldwide.
  • Three Color Temperatures Cool white, natural white and warm white to fit different machining observation.
  • IP67 Superior Protection Integrated sealed design, waterproof, oil-proof, dustproof against cutting fluid.
  • Shock-resistant & Durable Aluminum housing and tempered glass, stable under continuous machine vibration.
  • Compact Tubular Structure Small footprint, easy integration for narrow installation space on equipment.

Applications

CNC machining centers, SMT lines, automated packaging, injection molding, robotics workcells, conveyors, and industrial warning systems.

Package Info

9 pieces/carton, 990x210x240mm, N.W. 10kg, G.W. 13kg
